Pepper Grinding Machine

By: MILL 2022-04-14
Pepper Grinding Machine Description:

The pepper grinding machine is composed of a hammer host, an ultramicro host, a cyclone separator, and an impulse dust box. The grinding machine has a variety of properties such as no screen, no mesh, uniform discharge particle size, etc. Compact design, compared to the micro-grinding unit, more pre-processing hammer for coarse crushing, so that large particles of material can be directly crushed, continuous crushing process, no dust. Fine powder trapped by dust traps can be effectively recovered, reducing the material loss rate.

Pepper Grinding Machine

Grinding Machine Application:

The grinding machine can crush Chili, pepper, black pepper, white pepper, green pepper, cinnamon, cumin, bandits, Dahongpao pepper, cinnamon,nutmeg, cardamom, red yeast rice, red pepper, garlic, star anise, cloves, Amomum Tsaoko, geraniol, turmeric, ginger, fennel, anise,angelica and other material with high content of oil or tiber.

Pepper Grinding Machine

Grinding Machine Video:

Learn more about YouTube’s pepper grinding machine

Technical Parameter:
Model Main Structural Dimensions(mm) Capacity Input Particle Size Output Particle Size Speed Machine weight Total power
L1 L2 H1 H2 H3 H4 W1 Kg/H mm mesh rpm Kg KW
MR-30 4650 2540 1080 650 350 1380 100-400 <10 12-120 3800 850 11.25
MR-40 5200 2800 1150 650 350 1450 200-800 <12 12-120 3400 1200 15.75
MR-50 5450 7050 2800 1400 650 350 1550 280-1000 <15 12-120 2900 1350 26.75
MR-60 5800 7400 3150 1460 650 350 1550 300-1200 <15 12-120 2300 1500 30.25
MR-80 6100 7900 3250 1570 650 400 1600 400-1800 <20 12-120 1800 2100 48.75
MR-100 6750 8550 3350 1800 650 400 1750 500-2000 <20 12-120 1400 2400 64.25
Our company can be customized according to the user’s special requirements.
